Application:
The machine can finish the work of carton opening, shaping, folding and sticking the adhesive tape. It saves time and force. The machine can correct the right-angle automatically. It is very easy to adjust the size of the carton, and has wide usage. The machine has the function of easy operation to reduce the cost.
Technical Parameter:
Carton Size
L200-500 W150-400 H100-450mm
Speed
8-12 carton/min
Table height
750±50mm
Dimension
1700×1930×1500mm
Power supply
220/380 50/60Hz
Air source
5-6kg/cm3
Tape
48/60/72mm
Weight
600kg
