Product description：
Technical data:
Facility
type: AK-100A
External
dimension of the facility: L5050×W1120×H2100mm
Max.
Dimension of wrappage: L600×W320×H400mm
Shrink
film material: PE
Shrink
film thickness: 0.06-0.12mm
Thermo-shrink
tunnel Max. temperature: 160-230°( can be adjusted freely)
Max.
output per minute: 0-6pcs
Facility
power: 18Kw
Actual
power: 15Kw/h
Voltage:
380/220V
Facility
weight: 0.65T
Fan: 40w
220V 2units, 120w 380V 2units
The general specification of the machine
Pneumatic
component 1set
Speed
adjustment motor 1 set
Stainless
iron wing type heating tube
Stainless
steel convey belt
Thermo
sealing knife cast aluminum heating board has the character as even temperature,
long life, is our special product.
Whole
machine outer plastic-sprayed, the frame is made of high-quality carbon steel,
main part adopt to stainless steel.
Wooden
case and wrappage film packed separately.
