1. Parameters of Basic label & Bottle:
Model
HLML5
Capacity
10000-12000BPH
Label Size(Max)
330mm(L)*120mm(W)
Label thickness
0.028-0.05mm
Label material
OPP, BOPP, PP, PVC, PE, ETC,PAPER
Products for labeling
Round Bottles & Material: PE, PET, Glass
Power
380 Volts, 3 Phase, 50-60 Hz, 7.5Kw
Air consumption
340 - 450 L/min (5-6 Kg/Cm2)
Weight
Around 2500 Kg
Machine size
3730mm*1314mm*1800mm
2. Component of Host machine:
No.
Name
1
Conveyor chain
9
Rubberizing system
2
Conveyor screw
10
Hot glue melt machine
3
Bottle feeding thumbwheel
11
Bottle rubbed component
4
Main drive system
12
Bottle belt-hold component
5
Label hold & feeding
13
Vacuum pump
6
Traction system
14
Pneumatic system
7
Wheel-hub for label-holding
15
Electrical system
8
Wheel-hub for label-sticking
16
Main body frame-SUS304
