| NaHCO3
|
Purity≥99%
Max feeding capacity:150kg/time
|
| Concentrated sulphuric
|
Purity≥98%
Max feeding capacity90kg/time
|
| CO2 Production
|
Purity≥99%
Normal conditions Max39.6m3
|
| Pressure of Compressed gas (adjustable)
|
6-7kg/cm2
|
| Sulfuric acid tank total volume
|
60lts
|
| Reactor
|
Total volume :300lts (straight ),
Operating pressure(MPa): normal pressure,
Operating temperature: <80°C
|
| Mixer
|
Power:0.75kw,
Mixing speed:16.66 rpm,
ReducerModel:BLY12-87-0.75
|
| Diaphragm metering pump(adjustable)
|
Power supply:~380V(three phase), oPerating pressure(MPa):0.3~1.0 Mpa
|
| Air compressor
|
Volume:0.22m3/minute, Pressure:0.7MPa
|
| Gas purification unit
|
Operating pressure(MPa):0.8MPa,
Operating temperature:<50°C,
Measurement range of Flowmeter:0.6~6 m3/h(gas)
|
| Whole power
|
3.20kw
|
| Appearance size(mm)
|
5800×1800×2500mm
|
